AmmunitionM-21HE-ARS
122 mm Unguided Rocket M-21HE-ARS is designed to defeat the manpower of the enemy in the open and in field shelters, to push passages in minefields and defense facilities, against mortar batteries, field and rocket artillery and destruction of unarmored and light armored vehicles and other tasks in a combat environment.
Caliber, mm 122
Rocket weight, kg 66.18
Rocket length, mm 2750
Warhead weight, kg 18.4
Number of fragments, pcs:
-from the pre-fragmented part of warhead (with aver. weight 2.4 g) 1640
-from Warhead Body (with aver. weight 2.9 g) 2280
Maximum velocity, m/s 660
Maximum firing range, km 20.127
Operation temperature range, °C from minus 40 to 50
COMPLETION
Fuze AF81 (MRV-U)
Ballistic brake rings big and small
Wooden case dimensions, mm: 2810 x 290 x 260
Wooden case volume, m3 0.212
Wooden case GROSS weight, kg: 100
CLASS OF EXPLOSION HAZARD 1.2E, UN 0182
