81 mm Thermobaric Mortar Bombs TB 81
The Thermobaric Mortar Bombs TB81 are used for combined defeating, both by air-blast and thermal emission, of enemy manpower in urban areas, fortifications, transport means, and in the open.
Weapon compatibility:
81 mm Mortars of NATO Standard – M81MA, M1, M29A1, M29, L16 A1/A2, M8-522, M081-61C, Tampella, ECIA IN etc.
When firing with Mortar M29 do not fire over Charge 5.
When firing with Mortar M1 do not fire over Charge 4.
Body material Aluminum alloys
Length fuzed, mm 627
Weight fuzed, kg 4.250
Payload Thermobaric composition TBC-2
Highest Max Pressure, bar (piezo) 950 (0+6)
Fuze AF 610 arming distance, m not less than 40
Operating Temperature Range, °C from minus 40 to 50
Maximum Pressure, bar (piezo) 950 (0+6)
Max Range, m 5 136 (0+6)
5 466 (0+6)
1 170 mm barrel 5 136 (0+6)
1 450 mm barrel
Muzzle velocity, m/s 293 (0+6)
311 (0+6)
1 170 mm barrel
1 450 mm barrel
Class of explosion hazard: 1.2E, UN 0321
Type One fuzed Mortar Bomb with 6 pcs. Increment charges is packed in a Container; 6 pcs. Containers are arranged in a wooden case.
Wooden case dimensions, mm 750х353х270
Wooden case weight, kg 42
Case volume, m3 0.071
